Article No. 33368
SLOTTED COVERS 200, neck height 160, class C 250
Access cover, SW 12 mm, galvanised, asymmetric, 0.5 m
Available from stock
Questions?
Our experienced planning team will be happy to help you.
Get in touch
Product image
Technical drawing
Drawing (CAD)
Data Sheet
Technical information and metrics
Article No.
33368
Length
500 mm
Width
263 mm
Height
181 mm
Einlegetiefe
181 mm
Weight
9.06 kg
Material
strip galvanized steel
Intake cross-section
345.0 cm²/m
Nominal size
200
Inlet opening
12
Material cover
strip galvanized steel
Sales text
Access cover SW 12 mm, neck height 160 mm, galvanised, asymmetric, cl. C 250, FASERFIX KS/ RECYFIX PRO 200, 0.5 m
Product description
FASERFIX KS/ RECYFIX PRO 200 -Access cover for slotted cover SW 12 mm, neck height 160 mm, asymmetric, galvanised, load class A 15 - C 250 according to EN 1433, length 500 mm, item no. 33368
Packaging unit
-
