Article No. 32303
SLOTTED COVERS 100, neck height 105 mm, class C 250
Access cover SW 12 mm, galvanised, asymmetric, 0.5 m
Delivery time on request
Questions?
Our experienced planning team will be happy to help you.
Get in touch
Product image
Technical drawing
Drawing (CAD)
Drawing
Data Sheet
Technical information and metrics
Article No.
32303
Length
500 mm
Width
163 mm
Height
133 mm
Einlegetiefe
126 mm
Weight
5.22 kg
Material
strip galvanized steel
Intake cross-section
298.0 cm²/m
Nominal size
100
Inlet opening
12
Material cover
strip galvanized steel
Regulations
in accordance with EN 1433
Sales text
Access cover SW 12 mm, neck height 105 mm, galvanised, asymmetric, cl. C 250, FASERFIX KS/ FASERFIX STANDARD/ RECYFIX PRO 100, 0.5 m
Product description
FASERFIX KS/ FASERFIX STANDARD/ RECYFIX PRO 100 -Access cover for slotted cover SW 12 mm, neck height 105 mm, asymmetric, galvanised , load class A 15 - C 250 according to EN 1433, length 500 mm, item no. 32303
Packaging unit
84
