Article No. 32747
SLOTTED COVERS 100, neck height 105 mm, class C 250
Access cover SW 2 x 6 mm, stainless steel, asymmetric, 0.5 m
Available from stock
Questions?
Our experienced planning team will be happy to help you.
Get in touch
Product image
Technical drawing
Drawing (CAD)
Data Sheet
Technical information and metrics
Article No.
32747
Length
500 mm
Width
163 mm
Height
125 mm
Einlegetiefe
125 mm
Weight
6.76 kg
Material
Stainless steel 1.4301
Intake cross-section
264.0 cm²/m
Nominal size
100
Inlet opening
6
Material cover
Stainless steel 1.4301
Regulations
in accordance with EN 1433
Sales text
Access cover SW 2x6 mm, neck height 105 mm, stainless steel, asymmetric, cl. C 250, FASERFIX KS/ FASERFIX STANDARD/ RECYFIX PRO 100, 0.5 m
Product description
FASERFIX KS/ FASERFIX STANDARD/ RECYFIX PRO 100 -Access cover for duo slotted cover SW 2x6 mm, neck height 105 mm, asymmetric, stainless steel CNS 1.4301, load class A 15 - C 250 according to EN 1433, length 500 mm, item no. 32747
Packaging unit
84
Declaration of Performance
